Flexibles Rohr 1" 1/2 DIN EN 853 1SN / SAE 100R1
VERKAUFSPREIS PRO METER: 1 EINHEIT = 1 METER
28,79 €
Flexibles Rohr 2" DIN EN 853 1SN / SAE 100R1AT
VERKAUFSPREIS PRO METER: 1 EINHEIT = 1 METER
35,42 €
Flexibles Rohr 2"1/2 DIN EN 853 1SN / SAE 100R1
VERKAUFSPREIS PRO METER: 1 EINHEIT = 1 METER
62,54 €
Flexibles Rohr 3" DIN EN 853 1SN / SAE 100R1AT
VERKAUFSPREIS PRO METER: 1 EINHEIT = 1 METER
78,42 €
Flexibles Rohr 3/16" DIN EN 853 2SN / SAE 100R2A
VERKAUFSPREIS PRO METER: 1 EINHEIT = 1 METER
7,46 €
Adapter JIC-Außengewinde 1"5/8 auf Außengewinde 1"7/8 UNF
- Verschlussteil JIC-Kegel 37°. - UNF-Teilverschluss mittels O-Ring. - Kohlenstoffstahlmaterial. - Oberflächenbehandlung mit Dichromat.
25,88 €
Adapter JIC-Außengewinde 1"5/8 auf Außengewinde 1"5/8 UNF
- Verschlussteil JIC-Kegel 37°. - UNF-Teilverschluss mittels O-Ring. - Kohlenstoffstahlmaterial. - Oberflächenbehandlung mit Dichromat.
18,17 €
Adapter JIC-Außengewinde 1"5/8 auf Außengewinde 1"5/16 UNF
- Verschlussteil JIC-Kegel 37°. - UNF-Teilverschluss mittels O-Ring. - Kohlenstoffstahlmaterial. - Oberflächenbehandlung mit Dichromat.
23,08 €
Pumpenfluss | L / min. 1.500 U / min (US CPM 1500 U / min) | 1.5 (0,40) |
Verschiebung | cm3 / v - cc / rev (in3 / rev) | 1 (0,06) |
Maximaler Druck mach weiter | Pub (PSI) | 275 (3.990) |
Maximaler Druck inter 5 sek. max. | Pub (PSI) | 300 (4.350) |
U / min bei kontinuierlichem Druck | 5.000 | |
Maximale Drehzahl | 6.000 | |
Mindestdrehzahl je nach Druck | 100 bar (1.450 PSI) | 1.000 |
175 bar (2.540 PSI) | 1.500 | |
205 bar (3.625 PSI) | 2.000 | |
300 bar (4.350 PSI) | 3.000 | |
Empfohlenes Öl | ISO 6743 Typ HM, HV oder HG | |
Viskosität | ISO 3448 Kat.-Nr. VG32-VG46 | |
Ölreinheitsgrad | 19/16 s. ISO 4406 oder RP70H | |
Ölarbeitstemperatur | -20 ° C ... + 80 ° C. -4 ° F ... + 173 ° F. | |
Maximale Saugdepression | <0,3 bar |
