Adapter male JIC thread 1"5/8 to male thread 1"7/8 UNF
- Closing part JIC cone 37º. - UNF part closure using O-ring. - Carbon steel material. - Dichromate surface treatment.
25,88 €
Adapter male JIC thread 1"5/8 to male thread 1"5/8 UNF
- Closing part JIC cone 37º. - UNF part closure using O-ring. - Carbon steel material. - Dichromate surface treatment.
18,17 €
Adapter male JIC thread 1"5/8 to male thread 1"5/16 UNF
- Closing part JIC cone 37º. - UNF part closure using O-ring. - Carbon steel material. - Dichromate surface treatment.
23,08 €
Adapter male JIC thread 1"5/16 to male thread 1"5/8 UNF
- Closing part JIC cone 37º. - UNF part closure using O-ring. - Carbon steel material. - Dichromate surface treatment.
52,17 €
90° elbow threaded nut M-18X150 to hydraulic pipe Ø 12 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-18X150.- For hydraulic pipe Ø 12 outside.- Light series.- Material forged steel.- Bichromated anti-oxidation treatment.
7,13 €
90° elbow threaded nut M-16X150 to hydraulic pipe Ø 10 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-16X150.- For hydraulic pipe Ø 10 outside.- Light series.- Material forged steel.- Bichromated anti rust treatment.
7,67 €
90° elbow threaded nut M-16X150 to hydraulic pipe Ø 8 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-16X150.- For hydraulic pipe Ø 8 outside.- Heavy series.- Material forged steel.- Bichromated anti rust treatment.
5,75 €
90° elbow threaded nut M-14X150 to hydraulic pipe Ø 8 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-14X150.- For hydraulic pipe Ø 8 outside.- Light series.- Material forged steel.- Bichromated anti-oxidation treatment.
5,88 €
FEATURES:
- Compliance with RoHS regulations.
- Quick application thanks to the design of the head.
- Non aggressive edges.
- Resistance of the internal teeth that prevents slipping.
- Bending of the tip that facilitates the introduction into the piece.
- Easy sliding and resistance to breakage.
MEASURE | WIDTH (A) mm | LENGTH (L) mm | Ø MAXIMUM USEFUL | RESISTANCE IN KGS. |
2.5 x 100 | 2.5 | 100 | 22 | 8 |
2.5 x 140 | 2.5 | 140 | 33 | 8 |
2.5 x 160 | 2.5 | 160 | 40 | 8 |
2.5 x 200 | 2.5 | 200 | 53 | 8 |
3.6 x 140 | 3.6 | 140 | 33 | 18 |
3.6 x 200 | 3.6 | 200 | 53 | 18 |
3.6 x 300 | 3.6 | 300 | 76 | 18 |
4.8 x 200 | 4.8 | 200 | fifty | 22 |
4.8 x 250 | 4.8 | 250 | 60 | 22 |
4.8 x 300 | 4.8 | 300 | 76 | 22 |
4.8 x 370 | 4.8 | 370 | 102 | 22 |
7.6 x 370 | 7.6 | 370 | 102 | 54.4 |
