All female threads:
- Cylindrical BSP.
Male thread:
- conical BSP;
- Cylindrical BSP.
REFERENCE | Ø TUBE | THREAD |
RAF 06M5 | 4X6 | 1/8 " |
RAF 1203 | 10x12 | 3/8 " |
RAF 1204 | 10x12 | 1/2 " |
Connection thread measurements:
M5 | 01 | 02 | 03 | 04 | 05 | 06 |
M5x0.8 | R-1/8 " | R-1/4 " | R-3/8 " | R-1/2 " | R-3/4 " | R-1 " |
Example: RAF 1203, corresponds to a 10x12 fitting and 3/8 "thread.
