Pressure gauge Ø 63 with glycerin from 0 to 300 bar with rear outlet

CONSTRUCTIVE AND FUNCTIONAL CHARACTERISTICS:

- Standard thread: 1/4".

- Accuracy: Class 1.6 according to EN 837-1.

- Ranges: From 0..300 bar or any other equivalent unit of pressure or vacuum, standard ranges according to DIN 16 128.

- Ambient temperature: -20...+65° C.

- Process medium temperature: max. +65° C.

- Temperature error: additional error when the temperature of the sensitive element deviates from 20° C +/- 0.3 % every 10° C variation.

- Working pressure:

Static max. 75% of V.F.E.

Fluctuating: 2/3 of E.F.V.

- Temporary overpressure: +25% for scales less than or equal to 100 bar, +15% for over 100 bar.

- Degree of protection: IP 65 according to IEC 529.

- Process connection fitting: brass.

- Tubular spring: Phosphor bronze "C" for scales ≤ 40 bar, spiral for scales > 40 bar.

- Housing: AISI 304.

- Closing ring: flanged, in AISI 304.

- Sight glass: transparent plastic, thickness 4 mm.

- Mechanism: brass.

- Indicator needle: black lacquered aluminum.

OTHER OPTIONS:

- Tin-silver alloy soldering.

- Glass sight glass.

- Special hose type connections.
