| Type | Slide valve not lockable |
Beginning of shutter | Hermetizante metallic |
Operating pressure min./max. | -0,95 bar / 10 bar |
Ambient temperature min./max. | -15°C / +80°C |
| Temperature of medium min./max. | -15°C / +80°C |
| Fluid | Compressed air |
| Nominal flow | 280 l/min. |
| Particle size max. | 5µ |
| Content of oil in the compressed air | 5mg/m3 - 25mg/m3 |
| Fixing screw | M4 with hexagon socket |
| Tightening torque of the fastening screw | 2.5 Nm |
TECHNICAL DATA:
| A drive element | Compressed air connection | Qn | Pair of drive Min. | ||
| Entry | Output | Escape | |||
| N | Nm | ||||
| Roller | G 1/8 | G 1/8 | G 1/8 | 6,5 | - |
