SALES PRICE PER METER: 1 UNIT = 1 METER
Availability : En stock, normalmente enviado en un día laboral
HID100432
Sleeve for parachute valve male thread 1" female thread 1".
- Sleeve for parachute valve.- Does not include inner valve.- Male 1" female 1" thread.- Carbon steel material.- Bichromated surface treatment.
10,75 €
Sleeve for parachute valve male thread 1/2" female thread 1/2".
6,95 €
Sleeve for parachute valve 1/4" male 1/4" female thread
7,11 €
Sleeve for parachute valve male thread 3/8" female thread 3/8".
15,48 €
Adapter 1/4" male 1/4" male 1/2" BSP thread reduction adapter
- BSP (Gas) thread reduction adapter.- 60° inverted cone.- Male 1/4" male 1/2" thread.- Carbon steel material.- Bichromated surface treatment.
2,38 €
Hose coupling with male thread 1"1/2 for hose Ø 40 mm
- Hose coupling with male thread.- Male thread 1"1/2.- For hose Ø 40 mm.- Material brass.
19,76 €
Bulkhead for tank thread 1" Stainless
25,99 €
Female thread 3/4" BSP female threaded hose fitting for hose inner Ø 20 mm
- Hose nut fitting.- 3/4" BSP female thread.- For hose Ø 20 mm inside.- Flat seat with NBR gasket.- Brass material.- Flat rubber gasket.
4,46 €
SALES PRICE PER METER: 1 UNIT = 1 METER
Availability : En stock, normalmente enviado en un día laboral
HID100432
- Hydraulic hose reinforced with double braided high-pressure steel
According to ISO 1436 / DIN EN 853 type 2SN / SAE J517 type SAE 100R2 AT
- Inner tube Ø 50.8 mm. Oil-resistant synthetic rubber without welding
- Reinforcement: 2 high tensile steel wire braids
- Outer tube Ø 67.4 mm. Synthetic rubber resistant to abrasion, weather and oil.
- Working pressure 80 Bar.
- Burst pressure 320 Bar.
- Safety factor: 4:1
- Application: petroleum based hydraulic fluids
- Temperature range: -40°C (-40°F) +100°C (+212°F); Intermittent service
- Max. Recommended temperature for water-based hydraulic fluids: +70°C (+158° F);
- Max. recommended air temperature: +60°C (+140° F)
The prices shown on the website do not include VAT
The shipping costs are calculated automatically in the cart according to the weight of the product and the place of delivery
