SPECIFICATIONS EXCEEDED:
DEXRON II-D ® - GENERAL MOTORS
MB 236.7
A. T. F. TYPE A SUFFIX TO
VOITH G 607
ALLISON C – 4
MAN 339D
ZF TE ML 03D / 04D / 14A / 17C
DESCRIPTION:
Lubricating oil formulated with bases of high degree of refining and specific additives for automatic transmissions of the previous generation that require a quality level of DEXRON® II-D.
PROPERTIES AND ADVANTAGES:
- High resistance against oxidation and corrosion
- Excellent anti-foaming and de-aeration, which allow for a smooth ride.
- Excellent low-temperature fluidity, reducing premature wear caused by cold starts.
- Due to its high viscosity index ensures proper lubrication at both high as low temperatures.
- Reduced deposit formation, while maintaining the planetary gears in an optimal state of cleanliness.
- Technology anti-wear minimizes the friction in the elements lubricated, therefore reducing fuel consumption.
- Compatible with common materials of sealing.
APPLICATIONS:
- Automatic transmissions with demands, DEXRON® II-D.
- Turboembragues, torque converters.
- Also recommended for units of power steering and certain manual transmissions.
- Hydraulic systems which require a fluid according to DIN 51524 part 2 (HLP) and part 3 (HVLP) grade ISO 46.
SPECIFICATIONS / QUALITY LEVEL:
| API GL4 MB | 236.1 / 236.2 / 236.7 |
GM DEXRON® II-D | MAN 339 A/D |
| FORD MERCON ® | ZF TE ML-09TH / 11TH |
| ALLISON C3 / C4 | CATERPILLAR TO-2 |
TECHNICAL DATA:
PRESENTATION:
Bottles of ½ L and 5 L, Drums 200 L.
| CHARACTERISTICS PHYSICAL-CHEMICAL | STANDARD | VALUE |
| SAE grade | SAE J-306 | 75W80 |
| Viscosity at 100 ºC, Min (cSt) | ASTM D-445 | 5,5 |
| Viscosity index, Min | ASTM D-2270 | 140 |
| Density at 15 ° C, Typical (kg/l) | ASTM D-1298 | 0,860 |
| Freezing point, Max (°C) | ASTM D-97 | -44 |
| Flash point (°C) | ASTM D-92 | 190 |
PRESENTATION:
Bottles of ½ L and 5 L, Drums 200 L.
