90° elbow threaded nut M-18X150 to hydraulic pipe Ø 12 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-18X150.- For hydraulic pipe Ø 12 outside.- Light series.- Material forged steel.- Bichromated anti-oxidation treatment.
7,13 €
90° elbow threaded nut M-16X150 to hydraulic pipe Ø 10 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-16X150.- For hydraulic pipe Ø 10 outside.- Light series.- Material forged steel.- Bichromated anti rust treatment.
7,67 €
90° elbow threaded nut M-16X150 to hydraulic pipe Ø 8 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-16X150.- For hydraulic pipe Ø 8 outside.- Heavy series.- Material forged steel.- Bichromated anti rust treatment.
5,75 €
90° elbow threaded nut M-14X150 to hydraulic pipe Ø 8 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-14X150.- For hydraulic pipe Ø 8 outside.- Light series.- Material forged steel.- Bichromated anti-oxidation treatment.
5,88 €
90° elbow threaded nut M-14X150 to hydraulic pipe Ø 6 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-14X150.- For hydraulic pipe Ø 6 outside.- Peasda series.- Material forged steel.- Bichromated anti rust treatment.
5,13 €
90° elbow threaded nut M-12X150 to hydraulic pipe Ø 6 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-12X150.- For hydraulic pipe Ø 6 outside.- Light series.- Material forged steel.- Bichromated anti-oxidation treatment.
4,63 €
90° elbow threaded nut M-24X150 to hydraulic pipe Ø 16 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-24X150.- For hydraulic pipe Ø 16 outside.- Heavy series.- Material forged steel.- Bichromated anti-oxidation treatment.
11,50 €
90° elbow threaded nut M-22X150 to hydraulic pipe Ø 15 outside DIN 2353
- 90º elbow nut nut to hydraulic pipe DIN 2353.- Thread nut nut M-22X150.- For hydraulic pipe Ø 15 outside.- Light series.- Material forged steel.- Bichromated antioxide treatment.
7,83 €
PROPERTIES:
- Reduces noise in submerged brakes.
- Provides excellent braking ability and gear protection.
- Excellent anti-wear capacity.
- High thermal and chemical stability.
- Demonstrated compatibility with copper alloys used in synchronism and piston pumps.
- Long service life, maintaining stable friction control.
- Superior cleaning, avoiding the formation of deposits and lacquers inside the circuits.
- Guaranteed protection of the system against corrosion.
APPLICATIONS:
- Fluid type UTTO specially designed for systems subjected to strong thermal loads.
- Hydraulic systems, transmissions, final reducers.
- Rear transmissions with oil immersed brakes, side reducers, wheel reducers, differentials.
- Mechanical and hydrostatic steering or power steering of tractors, agricultural machinery in general and public works machinery.
SPECS:
JOHN DEERE JDM J20C, J20D | FNHA-2-C-200.00, FNHA-2-C-201.00 |
CASE MS 1210 | KUBOTA-UDT Fluid |
CASE NEW HOLLAND CNH MAT 3509, 3505, 3525, 3540 | ALLISON C4 |
HCE-102, HCE-102W | VALTRA G2-08 |
AGCO POWERFLUID 821XL | CATERPILLAR TO-2 |
MASSEY FERGUSON CMS M1135, M1141, M1143, M1145 | API GL-4 / SAE 80W |
FORD ESN-M2C86-B, ESN-M2C86-C, ESN-M2C134-D | FENDT |
ZF TE-ML 03E, 05F, 06E, 06F, 06K, 17E, 21F | VCE WB 101 |
TECHNICAL DATA:
PHYSICOCHEMICAL CHARACTERISTICS | RULE | VALUE |
SAE grade | SAE J300 | 10W30 |
ISO grade | ISO 3448 | 68 |
Viscosity at 100 ºC (cSt) | ASTM D-445 | 9.3 - 12.5 |
Freezing point ºC (ºF), Max. | AST M D-445 | -30 (-22) |
Flash point ºC (ºF), Min. | ASTM D-2270 | 200 (392) |
Copper Corrosion (3h 150ºC, 302ºF) | ASTM D-1298 | 1 B |
Submerged brake wear test | ASTM D-97 | Pass |
Wear Test, 4 Balls, (40 kg / 1200rpm / 75ºC / 1h), Footprint (mm) | ASTM D-92 | <0.40 |
Oxidation test on steel | ASTM D-130 | Pass |
Remarks :
- T ractor10W30 FS meets the requirements as UTTO fluid of the manufacturers:
DEUTZ, FIAT-HESSTON, I.HC, LANDINI, PERMATRAN, OLIVER, RENK, STEIGER, VERSATILE, WHITE.
- T ractor10W30 FS is suitable for applications where lubricants with CASE MS 1207 and CASE MS1209 specifications are recommended.
PRESENTATION:
5 L and 20 L containers, 200 L drums and 1,000 L containers.
